Gymnastic Swedish wall of polypropylene pipes

Gymnastic Swedish wall of polypropylene pipes

Gymnastic wall made with their own hands at a cost of approximately 10 times cheaper than the purchase. Although from the purchase is not much different. You do not need to be a great expert in soldering pipes to assemble it from polypropylene pipes. This Swedish wall I made for my child. It is able to withstand up to 80 kilograms, which is quite acceptable for school-age children.
It’s not for me to explain to you how gymnastics is useful for children, especially for strengthening the muscles of the spine. And the prices for such gymnastic installations leave nothing to be desired ...
These criteria and pushed me to think and make this wall of polypropylene pipes for my son.
Gymnastic Swedish wall of polypropylene pipes

The son drew a picture, he wanted this for a long time.

Getting Started


What you need:
  • Pipes are inch, with a diameter of 33 mm.
  • Fitting to pipes.
  • Soldering iron for polypropylene pipes.
  • Paint if desired.

You will have to calculate everything yourself for your requests. Take into account the height of the ceiling, etc. things.
As you all calculated, we cut the workpiece. And we start to solder the knots. You can remove the black markings with alcohol beforehand in order to avoid this. But you can of course erase it and in the end it won't be worse.
Gymnastic Swedish wall of polypropylene pipes

Gymnastic Swedish wall of polypropylene pipes

Gymnastic Swedish wall of polypropylene pipes

Gymnastic Swedish wall of polypropylene pipes

For everything about everything, it took me about an hour and the wall was ready. I recommend making soldering in open areas, as it all stinks terribly if you work for a long time. Also, be sure to use working gloves - the soldering iron is very hot and you will necessarily burn yourself if you have little experience in welding polypropylene pipes.
Please note that all pipe ends are sealed with plugs.
Gymnastic Swedish wall of polypropylene pipes

Gymnastic Swedish wall of polypropylene pipes

Gymnastic Swedish wall of polypropylene pipes

Gymnastic Swedish wall of polypropylene pipes

I painted the base in blue. To transitions were smooth - used masking tape.
Gymnastic Swedish wall of polypropylene pipes

Mounted gymnastic wall bars as follows. The entire length of the sides in the tees make holes. From the back side, we substitute the pre-cut and painted pieces of the same pipe and fasten it to the wall with long bolts. In the wall before this we make holes with plastic inserts.
Gymnastic Swedish wall of polypropylene pipes

Gymnastic rings are also made of pipe.To bend them into the ring, you need to heat the pipe along its entire length, and using a template like a wide-diameter pipe, cool it. Next solder jumper.
I bought the ropes, it's not going anywhere.
The child really likes - he just loved it!
Gymnastic Swedish wall of polypropylene pipes

Control tests weighing 75 kg.
Gymnastic Swedish wall of polypropylene pipes

The result met all expectations. It turned out to make beautiful and necessary is not difficult at all. Thank you all for your attention!
